Compressed Pallet Tshuab, Presswood Pallet Pwm Tshuab Paub meej:
Taw qhia ntawm sawdust pallet xovxwm tshuab
Lub tshuab moulded ntoo pallet tau raug txheeb xyuas los ntawm peb lub Hoobkas tau ntau xyoo, nrog kev ruaj ntseg zoo, kev ua haujlwm siab, kev siv hluav taws xob tsawg, kev teeb tsa yooj yim thiab kev nyab xeeb.Cov pwm yog rhuab nrog cov roj hloov hluav taws xob raws li cov cua sov.Lub tshuab presswood pallet yog lub zog-txuag, ruaj khov, yooj yim rau kev khiav lag luam, occupies ib cheeb tsam me me, tsis muaj tshwj xeeb yuav tsum tau rau lub rhiav, thiab muaj peev xwm tsim compressed pallets ntawm ntau yam specificationsCov pwm ntawm no hom ntawm cov ntoo recycling tshuab yuav customized raws li lub cov duab thiab qhov loj ntawm cov pallets koj xav tsim.Lub tshuab pallet compression ua los ntawm peb lub tuam txhab tau muab faib ua ib qho chaw nres tsheb pallet molding tshuab thiab ob lub chaw nres tsheb pallet molding tshuab.
Ua tshuab ntawm pallet compression tshuab
Presswood pallets khoom yog ib txheej ntawm molding pallet txoj kev machinery ntawm nws tus kheej tsim los ntawm peb lub tuam txhab.lub sawdust pwm xovxwm tshuab tuaj yeem ua tiav tag nrho cov haujlwm.Nyob rau hauv tus txheej txheem ntawm kev ua, cov khoom yog muab tso rau hauv lub pwm ntawm cov ntoo pallet molding tshuab.Lub tshuab pallet molding tuaj yeem ua tiav tag nrho cov txheej txheem ntawm nias, tuav lub zog, lub sijhawm, siab nyem, demoulding thiab nqa.
Hom pallet molding tshuab
Ib qho chaw nres tsheb pallet molding tshuab
Muaj tsuas yog ib txheej ntawm pwm nyob rau hauv ib qho chaw nres tsheb pallet molding tshuab, thiab ib lub sij hawm tos yuav tsum tau thaum lub tshuab yog loaded, nias down, tswj siab, thiab qhib lub pwm.Kev ua haujlwm ntawm lub tshuab ua pallet tsis yog siab npaum li ntawm ob lub chaw nres tsheb pallet molding tshuab.
Ob chav chaw nres tsheb pallet molding tshuab
Lub tshuab ob-chaw nres tsheb xovxwm yog lub tshuab pallet nrov ntawm kev ua lag luam.Vim tias muaj peev xwm ntau lawm thiab txuag hluav taws xob ntau dua, nws tau txais kev pom zoo los ntawm ntau thiab ntau cov khoom siv pallet.Muaj ob txheej ntawm pwm nyob rau hauv ob-chaw nres tsheb xovxwm uas muaj peev xwm txheej txheem pallets nyob rau hauv lem, thiab cov kev ua tau zoo dua.Ob txheej pwm tuaj yeem txav mus rau qhov sib npaug hauv qab ntawm lub tshuab servo tsav.Thaum ib txheej pwm siv los tuav lub siab thiab zoo li lub pallet sab hauv, lwm txheej pwm tuaj yeem siv rau kev pub noj, ntxiv cov khoom siv raw rau hauv pwm thiab flattening nws.Cov xovxwm ob lub chaw nres tsheb yog tus kheej tsim los ntawm peb lub tuam txhab txhawm rau txhawm rau daws qhov kev ua haujlwm qis ntawm cov tsoos compressed pallets hauv kev xyaum ntau lawm.Nws muaj txoj cai ywj pheej ywj pheej kiag li.Lub tshuab ua haujlwm ruaj khov thiab txuag lub sijhawm xav tau los ua ib qho pallet.Lub tshuab nqi ntawm ob-chaw nres tsheb pallet xovxwm tsis ntau siab dua li ntawm ib lub chaw nres tsheb xovxwm, tab sis lub peev xwm ntau lawm tau zoo heev.Tam sim no, nws tau dhau los ua cov khoom tseem ceeb molded pallet ua khoom ntawm lub khw.
Technical parameters ntawm pallet molding tshuab
| Qauv | ib qho chaw nres tsheb PM-1000 | Ob chav chaw nres tsheb PM-1000D |
| Cov khoom siv raw: ntoo chips, khib nyiab ntoo, flax, qab zib cane bagasse | ||
| Pallet loj: 1.2x1.0m / 1.2x0.8m ( txais customized) | ||
| Main qauv: 3 beam 4 kem | ||
| Khoom siv: lub moj khaum Q235A;kem: 45 # pwm: 45 # | ||
| Siab: 1000 (Ton) | ||
| Txhawb LOGO customized | ||
| Pallet hnyav: 18Kg / 20Kg / 22Kg; Dynamic load: 1.5-2 Tons; Statics load: 6-9Tons | ||
| Smart Gateway: Khiav lub xeev, muaj peev xwm ntau lawm thiab kev tswj hwm kev tswj hwm tuaj yeem tswj hwm online. | ||
| Cov khoom siv hluav taws xob: Schneider; PLC: Siemens lossis Mitsubishi; Screen: Weview; Servo motor hom: Albert | ||
| Muaj peev xwm: | 160-180 pcs / 24h | 220-240 pcs / 24h |
| Pwm naj npawb: | ib sab pwm thiab ib sab pwm | ib lub pwm sab saud thiab ob sab pwm |
| Dimension | 2000x1800x4850mm | 4800x2100x5250mm |
| Qhov hnyav | 22 Tons | 37 ton |
Nta ntawm ntoo pallet xovxwm tshuab
1 Peb tau kho dua tshiab thiab ua kom zoo dua cov qauv ntawm lub tshuab qub, thiab tau txais cov qauv peb-kab plaub-kem, uas yooj yim, kev lag luam thiab siv tau.
2. Lub hydraulic tswj tau txais kev sib koom ua ke ntawm cov cartridge valve, uas muaj kev txhim khu kev qha, lub neej ntev kev pab cuam thiab me me hydraulic shock, uas txo cov roj to ntawm cov kav dej txuas.
3. Lub tshuab tag nrho muaj kev tswj xyuas hluav taws xob ywj pheej, uas muaj kev ntseeg siab hauv kev ua haujlwm, lub hom phiaj hauv kev ua haujlwm thiab yooj yim hauv kev saib xyuas.
4. Txais khawm centralized tswj, nrog peb hom kev ua haujlwm: kev hloov kho, phau ntawv thiab semi-automatic.
5. Los ntawm kev xaiv lub vaj huam sib luag ua haujlwm, ob qho kev tsim cov txheej txheem ntawm cov hlab ntsha ruaj khov thiab lub siab tsis tu ncua tuaj yeem pom tau, thiab nws muaj cov haujlwm xws li lub zog tuav thiab ncua sijhawm.
6. Kev ua haujlwm siab ntawm cov pwm, kev mus los ntawm qhov tsis muaj kev thauj khoom sai sai thiab qeeb ua haujlwm ua ntej tuaj yeem hloov kho raws li cov txheej txheem xav tau.
Raw khoom rau compressed ntoo pallet tshuab
Cov khoom siv raw rau molded pallets tuaj yeem yog cov ntoo khib nyiab, sawdust, sawdust, shavings, cav, burnt hav zoov, planks, ceg, ntoo chips, khib nyiab pallets, thiab lwm yam thiab ntoo ua residues (slabs, slats, vaj ntoo core, khib nyiab veneer, lwm yam).Nws kuj tseem siv tau rau cov khoom siv tsis yog ntoo (xws li hemp stalk, paj rwb stalk, reed, xyoob, thiab lwm yam).Cov khoom siv raw uas muaj fiber ntau tuaj yeem siv los tsim cov pallets, xws li straw, cov ntawv pov tseg, xyoob, xibtes ntoo, txiv maj phaub, cork, nplej straw, bagasse, miscanthus, thiab lwm yam. Ua ntej molding cov ntaub ntawv raw, nws yuav tsum tau crushed rau. qhov loj me uas yuav tsum tau muaj rau kev tsim khoom, kom cov fibers ntawm cov khoom siv raw khoom zoo huv si, thiab cov khoom zoo nkauj dua.
Qhov zoo ntawm ntoo pallet hydraulic tshuab
High precision
Lub tshuab compressed ntoo pallet yog cov qauv ntsug ntawm plaub-kem hydraulic xovxwm.Lub thav duab adopts peb-beam plaub-kem qauv, uas muaj lub zog zoo, rigidity thiab precision tuav.
high degree ntawm automation
Lub tshuab kub xovxwm rau pallet txais kev koom ua ke ntawm lub tshuab, hluav taws xob thiab kua, thiab kev ua haujlwm ntawm txhua qhov yog tswj los ntawm PLC system.Lub tshuab tsis siv neeg hydraulic pallet tuaj yeem ua haujlwm los ntawm kev teeb tsa tsis tau los ntawm lub vijtsam kov.
tus nqi qis
Cov ntaub ntawv raw ntawm molded ntoo pallets tau yooj yim muaj thiab cov nqi tsim khoom tsawg.Ntau cov ntaub ntawv raw tuaj yeem ua rau hauv pwm pallets, xws li sawdust, cav, ntoo, ntoo shavings, khib ntoo, khib nyiab pallets, straw, thiab lwm yam.
Kev txuag hluav taws xob thiab kev tiv thaiv ib puag ncig
Ntau yam ntoo khib nyiab feem ntau yog siv rau hauv kev tsim cov pallets, uas ua rau kev siv cov khoom siv txuas ntxiv dua tshiab thiab muaj kev nyab xeeb dua.Hauv cov txheej txheem tsim khoom, tsis muaj dej khib nyiab thiab khib nyiab yuav raug tsim tawm, uas ua rau muaj kev ua qias tuaj ib puag ncig.
